Kugwiritsa Ntchito Kwambiri kwa Ma Transformer a Voltage Yaikulu: Zipangizo Zapakati Kuyambira Machitidwe Amagetsi Mpaka Zochitika Zamakampani

Chosinthira Chamagetsi ChapamwambaZimagwira ntchito ngati zida zofunika kwambiri pakutumiza mphamvu ndi kupanga mafakitale, ndipo ntchito zake zikuphatikizapo mphamvu, kupanga, chisamaliro chaumoyo, ndi magawo ena ofunikira. Nkhaniyi ikufotokoza ntchito zofunika kwambiri za ma transformer amphamvu kwambiri m'gulu lamakono kudzera m'mfundo zaukadaulo, zochitika zogwiritsira ntchito, ndi maphunziro a makampani.



1. Maudindo Ofunika Kwambiri mu Machitidwe Amphamvu

1. "Mphamvu Yowonjezera Mphamvu" Yotumizira Maulendo Ataliatali

Ma transformer amphamvu kwambiri amawonjezera mphamvu ya magetsi ya 10-35kV yopangidwa ndi magetsi kufika pa 220kV kapena kupitirira apo, zomwe zimachepetsa kwambiri mphamvu ya magetsi m'mizere yotumizira magetsi ndikuchepetsa kutayika kwa mphamvu (ndi 90%). Mwachitsanzo, mu West-East Power Transmission Project yaku China, ma transformer amphamvu kwambiri (UHV) amawonjezera mphamvu ya magetsi kufika pa 1000kV, zomwe zimathandiza kuti magetsi azitha kuyenda bwino pa mtunda wa makilomita 3,000.

2. "Smart Regulator" ya Grid Nodes

Mu malo osinthira magetsi, ma transformer amphamvu kwambiri amachita kusintha kwa magetsi ndi kubwezera mphamvu yogwira ntchito:



Kugawa kwa magawo:Kuchepetsa mphamvu ya magetsi yotumizira magiya kuchokera pa 220kV kufika pa 10kV/35kV pa ma gridi a m'madera osiyanasiyana.



Kukhazikika kwa voteji:Kugwiritsa ntchito zosinthira pa pompo (monga, ±10% kusintha) kuti muyankhe mosinthasintha kwa load ndikuwonetsetsa kuti gridiyo ili yokhazikika.





II. Ntchito Zamakampani Zosiyanasiyana

1. "Power Core" ya Makampani Olemera



Zachitsulo:Kupereka10kV-35kVmagetsi ogwiritsira ntchito ma uvuni amagetsi ndi ma uvuni oyambitsa kuti athandizire kusungunula chitsulo champhamvu kwambiri.



Zomera za mankhwala:Kuyendetsa ma electrolyzer ndi ma compressor akuluakulu, monga6-10kVma transformer apadera opangira chlor-alkali.



2 "Chosinthira Cholondola" cha Kupanga Zinthu Zapamwamba



Kupanga ma semiconductor:Makina odulira a Wafer amafunikaharmonic yotsika kwambirimphamvu yamagetsi amphamvu (monga kalasi ya 40kV), ndi ma transformer akukwaniritsa miyezo yokhwima ya THD



Kudula kwa laser:Ma laser a CO₂ amadalira20-50kVma transformer amphamvu kwambiri kuti apange plasma, pomwe kulondola kumakhudza mwachindunji ubwino wodula.



III. Zatsopano mu Mphamvu Zongowonjezedwanso

1. "Mlatho wa Gridi" wa Mphamvu ya Dzuwa ndi Mphepo



Mafamu a dzuwa:Kutembenuza mphamvu ya 0.8-1.5kV DC kuchokera ku ma PV arrays kupita ku 35kV AC, kenako kukwera mpaka 132kV grid voltage (monga Ningxia's 2GW solar project).



Mphepo ya m'mphepete mwa nyanja:Kugwiritsa ntchito malo osinthira magetsi a 66kVutomoni wopangidwa ndi pulasitiki Transformer Youmaskuti isamavutike ndi nkhungu ya mchere komanso kuti isagwire ntchito mosasamala.



2. "Malo Osungira Mphamvu" a Machitidwe Osungira Zinthu



Kusungira batri:Ma transformer amphamvu kwambiri amathandizaKusintha kwa DC/AC mbali zonse ziwiripakuwongolera ma gridi pafupipafupi (monga ma transformer a Tesla Megapack a 2.5MVA).





IV. Thandizo Lofunika Kwambiri pa Mapulogalamu Apadera

1. "Woteteza Chitetezo" pa Zipangizo Zachipatala



Kuzindikira zithunzi:Makina a X-ray ndi CT amafunika80-150kVmagetsi, okhala ndi ma transformer ogwirizana ndiMiyezo yachipatala ya IEC 60601zotetezera kutentha ndi EMC.



Zipangizo zochiritsira:Ma linear accelerators ogwiritsidwa ntchito pa radiotherapyma transformer amphamvu kwambiri(yankho la nanosecond) lokhala ndi kulekerera zolakwika



2 "Chida Cholondola" cha Kafukufuku wa Sayansi



Zothandizira tinthu tating'onoting'ono:CERN imagwira ntchitoMa transformer a resonant a 400kVkupanga minda yofulumira ya tinthu tating'onoting'ono.



Kuyesa kwamphamvu kwambiri:Mayeso a zinthu zotetezera kutentha amafunikaMa transformer oyesera ma frequency a mphamvu ya 1000kVkutsanzira mikhalidwe yoopsa kwambiri.



V. Zochitika Zachitukuko Zamtsogolo

1. Kukweza Mwanzeru

Kuwunika momwe zinthu zilili:DGA Yophatikizidwa (kusanthula mpweya wosungunuka) ndi masensa otentha a fiber-optic kuti azisamalira bwino (monga yankho la ABB's TXpert™).

Mapasa a digito:Kupanga chitsanzo cha 3D kuti kudziwike nthawi yomwe transformer idzakhalire, kuchepetsa ndalama zomwe zimagwiritsidwa ntchito pa O&M ndi 30%+.



2. Zatsopano Zaukadaulo Wobiriwira



Zipangizo zosawononga chilengedwe:Mafuta a ester owonongeka amalowa m'malo mwa mafuta amchere (malo oyaka moto okwera kufika pa 300°C).



Mapangidwe ogwira ntchito bwino kwambiri:Ma transformer a amorphous core amachepetsa kutayika kwa katundu ndi 70%, abwino kwambiri pa katundu wochepa monga ma famu a dzuwa.
